Sungrow SBR Hoogspannings LFP batterij 9,6kW (SBR096)

The Sungrow SBR096 is a high-voltage battery that uses a lithium iron phosphate (LFP) battery. These batteries do not contain cobalt and are considered to be the safest and most sustainable battery chemical currently available. This also makes this type of home battery more environmentally friendly and future-oriented.

Sungrow’s SBR096 battery is modular, compact in size and designed for direct use. It offers a flexible capacity range from 9.6kWh to 102.4kWh. When combined with a three-phase Sungrow hybrid inverter, this battery can operate in the range of 5-50kW.

With the Sungrow application, users can access all the important information about energy production and storage of solar panels for energy management. Both inverters and batteries can be initialized with one click for automatic commissioning and real-time production management.

Sungrow SBR096 Features of lithium-ion household batteries

The Sungrow SBR096 lithium-ion household battery is suitable for four battery modules. The battery has a nominal capacity of 9.6kWh and a nominal DC power of 5.76 kWh. The nominal voltage is 192V.

The Sungrow SBR096 household battery has an IP rating of 55, allowing the battery module to be placed both indoors and outdoors. Using the plug-and-play principle, the battery can be easily connected with a hybrid inverter to an existing solar panel system.

In brief

Battery type :LiFePO4 column battery

– Nominal capacity :9.6 kWh

– Available capacity :9.6 kWh

– Nominal voltage :192v

– Operating voltage :150 to 219v

– Nominal DC power :5.76 kW

– Max. Charge and discharge power: 6.57kW

– Max. Charge and discharge current (continuous):30a

– Max. Charge and discharge current (10s pulse):42a

– Discharge depth :100%

– Short circuit current :1700a
